TX140 S1 Upgrade and Maintenance Manual 539
Cabling
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 90.
Ê If applicable, close the rack door as described in section "Closing the rack
door" on page 92.
16.6 Replacing the backup drive USB cable
Figure 369: Backup drive USB cable T26139-Y3973-V2
16.6.1 Required tools
● Preliminary and concluding steps: tool-less
● Replacing the backup drive USB cable: tool-less
Field Replaceable Units (FRU)
Average task duration: 10 minutes
