TX140 S1 Upgrade and Maintenance Manual 571
Appendix
17.1.2 Server rear
Figure 400: PRIMERGY TX140 S1 rear (example: standard PSU)
2ID card
"Mounting the rack front cover" on
page 77, "Mounting the front cover" on
page 82
3 Optical disk drive
"Mounting order for accessible drives" on
page 328
4 Backup drive
5 5.25-inch dummy module
6
Front panel module
including front USB
connectors
"Replacing the front panel module" on
page 372
7
Front panel module:
optional front LAN
connector
"Replacing the front LAN connector and
board" on page 408
