TX140 S1 Upgrade and Maintenance Manual 491
Cabling
16.1.1 Power cabling
2.5-inch HDD configuration (standard power supply)
Figure 320: Power cabling - 2.5-inch HDD model
10 Fan -
from fan module
to system board
oo
11
PSU power
cables (standard
power supply)
-
from PSU to
system board
oo
12
PSU power cable
(redundant
power supply)
T26139-
Y4034-V101
from power
distribution board
to system board
oo
No. Name
Cable
number
Routing
2.5"
HDD
model
3.5"
HDD
model
Table 11: List of used cables
Slot 3 PCIe x4
Slot 1 PCI 32 Bit / 33 MHz
Indicate CSS
SATA6
SATA5
SATA POWER
POWER1
HDD ACTIVITY
Slot 2 PCIe x1
Jumper
SATA MLC1
USB1 DAT
Mgmt. LAN
USB 9/10
Shared LAN
USB 7/8
Standard LAN
USB 5/6
Slot 4 PCIe x16
USB1AUX
FRONT LAN
UFM
INTRUSION
FAN2 SYS
TPM
PC2009
FAN1 SYS
FRONTPANEL
FAN1 CPU
for
slimline
ODD only
