TX140 S1
Upgrade and Maintenance Manual
247
Expansion cards and back
up un
its
Figure 1
19: C
onnecting t
he BBU cable (
example A)
Figure 120: Co
nnecting the B
BU cable (
example B)
Ê
Connect the BBU cable to the BBU.
V
CAUT
ION!
Make sure that the c
onnector side with the three dot
s is on the top (see
close-up). Otherwise you risk short-circ
uits.
246
248
