TX140 S1 Upgrade and Maintenance Manual 27
Introduction
Model lines for TX140 S1
There are two model lines for the TX140 S1 server:
– TX140 S1
– TX140 S1p
The following table provides an overview of the different features:
TX140 S1 TX140 S1p
System board D3049-Axx D3049-Bxx
Processors Intel
®
XEON
®
E3-1200
processor series
Intel
®
Pentium
®
processor
series
Intel
®
Core™ i3-2100
processor series
Intel
®
XEON
®
E3-1200v2
processor series
Intel
®
Pentium
®
processor
series
Intel
®
Core™ i3
processor series
Main Memory DDR3 UDIMM with 1333 MHz
speed
up to 21 GB/s bandwidth in
dual channel mode and 10.6
GB/s in single channel mode
DDR3 UDIMM with 1600 MHz
speed
up to 25.6 GB/s bandwidth in
dual channel mode and 12.8
GB/s in single channel mode
PCI slots 1x PCI 3.0 (32 Bit / 33MHz)
1x PCIe x16 Gen 2
1x PCIe x4 Gen 2
(mechanical x8)
1x PCIe x1 Gen 2
(mechanical x4 notched)
1x PCI 3.0 (32 Bit / 33MHz)
1x PCIe x16 Gen 3
1x PCIe x4 Gen 2
(mechanical x8)
1x PCIe x1 Gen 2
(mechanical x4 notched)
Table 1: Differences between TX140 S1 and TX140 S1p
