TX140 S1 Upgrade and Maintenance Manual 349
Accessible drives
Figure 204: Routing backup drive cables
Ê Run the USB and power cables through the cable clamps (see arrows) as
shown.
Ê Ensure that the 6-pin connector on the USB cable is connected to system
board connector USB1 DAT (see close-up).
