576 Upgrade and Maintenance Manual TX140 S1
Appendix
No. Print Description
1 POWER1 ATX power supply connector
2 PC2009 Power management connector
3 Frontpanel USB Front panel / USB connector
4SATA POWER
Power distribution for SAS / SATA backplanes and
accessible drives
5 FRONT LAN Slot for front LAN connector board
6 FAN2 SYS (not used)
7 FAN1 CPU (not used)
8SATA MLC1
SATA MLC connector for 3.5-inch HDD
configurations
9 HDD ACTIVITY (not used)
10 USB1 AUX (not used)
11 USB1 DAT USB connector for accessible backup drive
12 Intrusion Intrusion switch cable connector
13 UFM Connector for USB Flash Module (UFM)
14 SATA 6 SATA 6 connector
15 SATA 5 SATA 5 connector
16 TPM Connector for Trusted Platform Module (TPM)
17 FAN1 SYS Connector for system fan
