Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin
190-02954-01 Rev. A 107
Flight Management
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
3) Touch the GPS1 or GPS2 Button and select the GPS1 Status or GPS2 Status Button. The
button annunciator is green when enabled and gray when disabled.
4) Touch the RAIM Prediction Tab.
5) Touch the Location Button.
6) Touch the Waypoint Button to enter the location for which RAIM will be predicted.
Touch the Present Position Button to enter the aircraft current position as the prediction
location.
7) If the Waypoint Button was touched in step 6, enter the waypoint identifier using the
alphanumeric buttons or the large and small upper knobs. If the Present Position
Button was touched in step 6, proceed to step 9.
8) Touch the Enter Button. The location selected for RAIM prediction is now displayed on
the Location Button.
9) Touch the Arrival Time Button.
10) Enter the planned arrival time for the selected location using the numeric buttons.
11) Touch the Enter Button. The time is now displayed on the Arrival Time Button.
12) Touch the Arrival Date Button.
13) Touch the button for the desired year. If necessary, touch and drag in the window, or use
the Up and Down buttons to display the desired year.
14) Touch the button for the desired month. If necessary, touch and drag in the window, or
use the Up and Down buttons to display the desired month.
15) Touch the button for the desired day. If necessary, touch and drag in the window, or use
the Up and Down buttons to display the desired day. The selected date is now displayed
on the Arrival Date Button.
16) Touch the Compute RAIM Button. One of the following will be displayed in the ‘RAIM
Status:’ Field:
• ‘Computing’— RAIM calculation in progress.
• ‘Available’— RAIM is predicted to be available for the specified waypoint, time, and
date.
• ‘Not Available’— RAIM is predicted to be unavailable for the specified waypoint, time,
and date.
• ‘--------’— RAIM has not been computed for the specified waypoint, time, and date
combination.
• ‘Computing’—RAIM calculation in progress
• ‘Available’—RAIM is predicted to be available for the specified waypoint, time, and
date
• ‘Not Available’—RAIM is predicted to be unavailable for the specified waypoint, time,
and date
• ‘--------’—RAIM has not been computed for the specified waypoint, time, and date
combination
