Selecting the Altimeter Barometric Pressure Setting:
1) Turn the BARO Knob to select the desired setting. If the setting is entered into the
Altimeter Setting Preview Window, proceed to step 2.
2) Push the BARO Knob after descending past the barometric transition altitude.
Selecting standard barometric pressure:
Push the BARO Knob to select standard pressure; STD BARO is displayed in the
Barometric Setting box.
Changing Altimeter Barometric Pressure Setting Units:
1) From PFW Home, touch PFD Settings.
2) Scroll down, and touch the Baro Select Units Button.
3) Touch either the Inches (IN) or Hectopascals (HPA) Button.
Or:
1) Press the PFD Settings Softkey.
2) Press the Other PFD Settings Softkey.
3) Press the Altitude Units Softkey.
4) Press either the IN or HPA Softkey.
5) When finished, touch the Back Button.
Enabling/disabling Automatically Switch BARO:
1) From MFW Home, touch Utilities >Setup > Avionics Settings.
2) Touch the System Tab.
3) Touch the Automatically Switch BARO Button to turn the alert on or off.
Setting the Baro Transition Alert:
1) From the MFW Home Screen, touch Utilities >Setup > Avionics Settings.
2) Touch the Alerts Tab.
3) To enable the alert, touch the BARO Transition ALT Climb Button or BARO Transition
LVL Descent Button.
4) To set or change the Baro Transition Alert Altitude, touch the respective data field. Enter
the desired altitude or flight level on the keypad, and touch the Enter Button.
HORIZONTAL SITUATION INDICATOR (HSI)
Changing the HSI Display Format:
1) From PFW Home, touch PFD Map Settings.
2) Touch the Layout Button.
3) Touch the HSI Map Button.
Or:
