5) With ‘Auto’ selected, the Threshold Slider is no longer grayed out.
6) Move the slider left or right to set the desired threshold. Setting the Threshold Level
percentage to the same percentage shown as the Current PFD1 Backlight Level will cause
the Day/Night view to switch at the current backlight setting. Adjusting the Threshold
Level setting larger than the Current PFD1 Backlight Level will cause the display to
remain in Night Mode longer. Adjusting the Threshold Level setting smaller than the
Current PFD1 Backlight Level will cause the display to change to Day Mode sooner.
Viewing traffic on the IFR Low, IFR High, or VFR chart:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the ‘Sensor’ Tab. Touch the Traffic Button to enable the traffic overlay. A green
annunciator indicates the feature is enabled.
Configuring traffic overlay settings:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the ‘Sensor’ Tab. Touch the Traffic Settings Button, then touch the Map Settings
Button.
3) Touch the Symbols Button. Choose the range at which traffic symbols will be displayed
and below (e.g.,
100 nm and below).
4) Touch the Labels Button to enable the feature.
5) Touch the Labels Button with the nautical mile range below. Choose the range at which
traffic labels will be displayed and below (e.g., 100 nm and below).
Viewing weather on the IFR Low, IFR High, or VFR chart:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the ‘Sensor’ Tab. Touch the Graphical METARs Button, the NEXRAD Button, the
Datalink Lightning Button, the Stormscope Lightning Button, or the TFR Button.
The WX Source Button is used to select the source of weather information: SiriusXM,
Connext, or FIS-B Weather.
SATELLITE TELEPHONE & DATALINK SERVICES (OPTIONAL)
NOTE:
Do not rely solely upon datalink services to provide Temporary Flight Restric-
tion (TFR) information. Always confirm TFR information through official sources such
as Flight Service Stations or Air Traffic Control.
NOTE:
Separate accounts must be established to access the Iridium Satellite Network
for voice and Garmin Connext for data transmission of maintenance reports.
