1) Press the PFD Map Settings Softkey.
2) Press the Map Layout Softkey.
3) Press the HSI Map Softkey.
Adjusting the Selected Heading:
1) Turn the HDG Knob on the AFCS Controller to set the Selected Heading.
2) Push the HDG Knob to synchronize the bug to the current heading.
Adjusting the Selected Course:
1) Turn the upper knob to set the Selected Course.
2) Push the upper knob to re-center the CDI and return the course pointer to the bearing of
the active waypoint or navigation station.
Changing the Navigation Angle Setting:
1) From MFW Home, touch Utilities >Setup > Avionics Settings.
2) Touch the Units Tab.
3) Touch the Nav Angle Button.
4) Touch either the Magnetic ( º ) Button or True ( ºT ) Button.
Selecting Bearing Display and Changing Sources:
1) From PFW Home, touch the Bearing 1 Button or the Bearing 2 Button to change the
source with each touch (Off, GPS,NAV1, NAV2, ADF, BEST GLIDE, WPT).
2) To remove the bearing pointer and information, touch the Bearing 1 Button or the
Bearing 2 Button followed by the Off Button.
Or:
1) Press the PFD Settings Softkey.
2) Press the Bearing 1 Softkey or the Bearing 2 Softkey to change the source with each
touch (NAV1, NAV2, GPS, ADF, WPT, and Off).
COURSE DEVIATION INDICATOR (CDI)
Changing Navigation Sources:
From PFW Home, touch the Nav Source Button to select GPS, VOR1/VOR2, or LOC1/
LOC2.
Or:
1) Press the Active NAV Softkey to change from GPS to VOR1/LOC1.
2) Press the Active NAV Softkey again to change from VOR1/LOC1 to VOR2/LOC2.
3) Press the Active NAV Softkey a third time to return to GPS.
