Message Comments
ARSPC NEAR – Airspace near –
less than 2 nm.
Special use airspace is within 2 nm of the aircraft position.
Airspace Alert Messages
VERTICAL SITUATION DISPLAY MESSAGES
Under certain conditions, some messages may appear in conjunction with others:
Message Description
‘Loading…’ VSD is loading data due to a range change, full/half
switch, or first being selected for display.
‘Flight Plan Not Available’ Flight Plan mode is selected and there is not a
flight plan loaded with at least one leg.
‘Flight Plan mode unavailable because aircraft off
course and active leg over 200 NM’
All of the following are true:
– Flight Plan mode is selected
– The active leg is greater than 200 nm
– The aircraft is outside the swath
‘VSD Not Available’ At least one of the following is true:
– Valid terrain database not available
– Current barometric altitude not available
– Current heading is not available
– GPS position not available
– An invalid range error has occurred
VSD Messages
IMPORTING AND EXPORTING FLIGHT PLAN MESSAGES
In some circumstances, flight plan import or export messages may appear in a pop-up win-
dow in conjunction with others.
Flight Plan Import/Export
Results
Description
‘Flight plan successfully
imported.’
A flight plan file stored on the SD card was successfully
imported as a stored flight plan.
‘File contained user waypoints
only. User waypoints
imported successfully. No
stored flight plan data was
modified.’
The file stored on the SD card did not contain a flight plan,
only user waypoints. These waypoints have been saved to the
system user waypoints. No flight plans stored in the system
have been modified.
