Condition Annunciation Description
Rudder Mistrim
Right
RUDñ
Yaw servo providing sustained force in the indicated
direction.
- Aircraft rudder pilot adjustment after substantial pitch
and power changes required
Rudder Mistrim Left
œRUD
Preflight Test
PFT
Performing preflight system test; aural alert sounds at
completion
- Do not press the AP DISC Switch during servo power-on
and preflight system tests as this may cause the preflight
system test to fail or never to start (if servos fail their
power-on tests). Power must be cycled to the servos to
remedy the situation.
PFT
Preflight system test failed; aural alert sounds at failure
Hypoxia Recognition
System is Activated
EDM
Activated only by the Hypoxia Recognition System
AFCS Status Alerts
SURFACEWATCH ALERTS
The SurfaceWatch alert annunciations are displayed in the central portion of the PFW. The
alert annunciations are accompanied by a corresponding voice alert. Other associated informa-
tion is presented in the SurfaceWatch Information Box.
Alert Annunciation
Associated
Voice Alert
Description
TWY TAKEOFF
“Taxiway”
Issued when the aircraft is taking off from or landing on a
non-runway (e.g., a taxiway).
TWY LANDING
RWY TOO SHORT
“Runway too
short”
Issued when the aircraft is taking off from or landing on a
runway with a length less than needed as calculated by the
system.
- The Runway Too Short Alert may be issued for any
runway from which the aircraft is taking off from, or
landing on, even if the runway is not the one entered
by crew.
CHECK RUNWAY
“Check
runway”
Issued when the aircraft is taking off from or landing on a
runway different than that entered into the system.
SurfaceWatch Alert Annunciations
