TAKEOFF AND LANDING ASSISTANT (TOLA)
TAKEOFF DATA
The 'Configuration Monitor' Box on the 'Takeoff Data' Pane will display an amber message
(example: 'FPL APT MISMATCH') for each item that is currently set differently than its planned
takeoff setting.
Message Condition
FLAPS
MISMATCH
When in the takeoff phase, the flaps setting selected in TOLA for takeoff differs from the
current flaps setting as detected by the flight deck.
FPL APT
MISMATCH
The departure airport in the active flight plan is not the same as the departure airport on
the Origin Tab.
FPL RWY
MISMATCH
The departure runway in the active flight plan is not the same as the departure runway
on the Origin Tab.
Takeoff Configuration Monitor Messages
LANDING DATA
The 'Configuration Monitor' Box on the 'Landing Data' Pane will display an amber mes-
sage (example: 'FPL RWY MISMATCH') for each item that is currently set differently than its
planned landing setting.
Message Condition
FLAPS
MISMATCH
When in the landing phase, the actual flaps setting is not the same as the flaps setting on
the Landing Config Tab.
FPL APT
MISMATCH
The destination airport in the active flight plan is not the same as the destination airport
on the DEST Tab.
FPL RWY
MISMATCH
The destination runway in the active flight plan is not the same as the destination runway
on the DEST Tab.
Landing Configuration Monitor Messages
FIS-B WEATHER ANNUNCIATIONS
FIS-B Weather Status Banner Annunciation Description
FIS-B WEATHER UNAVAILABLE
Current aircraft position is outside the FIS-B
Coverage area.
NOT RECEIVING WEATHER DATA
GTX
™
345R is currently off-line or not receiving
FIS-B Weather data from the antenna.
FIS-B Weather Status Annunciation
