Enabling/disabling Absolute Terrain + Relative Terrain Information on the Inset Naviga-
tion Map and HSI Map:
1) From PFW Home, touch PFD Map Settings Button.
2) If the HSI Map is not presently shown on the PFD, do the following:
a) Touch the Layout Button.
b) Touch the HSI Map Button to display the HSI Map.
3) Touch the Terrain Button.
4) Touch the Absolute + Relative Button to enable Absolute + Relative Terrain feature, or
Off to remove terrain information.
Or:
1) Press the PFD Map Settings Softkey.
2) Press the Terrain Settings Softkey.
3) Press the Absolute + Relative Softkey.
TERRAIN-SVT AND TAWS-B TERRAIN AND OBSTACLE ALERTS
Acknowledging Terrain Alerts:
1) Touch the Terrain-SVT or TAWS Button to display the terrain pane and terrain
settings screen.
2) Touch the OK Button to remove the pop-up alert.
Or:
Touch the Terrain Inhibit or TAWS Inhibit Button to inhibit the terrain system from
issuing alerts.
Inhibiting/enabling Terrain SVT alerting:
1) From MFW Home, touch Terrain SVT > Terrain SVT Settings.
Or:
a) From MFW Home, touch Map > Map Selection > Map Settings.
b) If not selected, touch the Sensor Tab.
c) Touch the Terrain Settings Button.
Or:
a) From PFW Home, touch PFD Map Settings.
b) If not selected, touch the HSI Map or Inset Map button to enable the Overlays
buttons.
c) Touch the Terrain Settings Button.
2) Touch the Terrain Inhibit Button. When the annunciator on the button is green, Terrain
SVT alerting is inhibited. When the annunciator is gray, Terrain SVT alerting is enabled.
