Displaying/removing the VOR compass rose:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Aviation Tab, if necessary.
3) Scroll the list to find the VOR buttons.
4) Touch the VOR Settings Button to display the 'VOR Settings' Window.
5) Touch the Compass Rose Button to display/remove the VOR compass rose.
Adjusting the map detail:
1) From MFW Home, touch Map > Map Selection > Map Settings > Map Detail.
2) Slide up or down on the Map Detail Slider to adjust the map detail.
Adjusting the PFW Map Detail:
1) From PFW Home, touch PFD Map Settings > Map Detail.
2) Slide up or down on the Map Detail Slider to adjust the PFW Map detail.
Or:
1) Press the PFD Map Settings Softkey on the PFW.
2) Press the Detail Softkey, as required, to cycle to the desired PFW Map detail.
ADDITIONAL MAP DISPLAY ITEMS
Displaying/removing other map items:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Other Tab, if needed.
3) Scroll as required and touch the desired button to display/remove map items.
Selecting track vector look-ahead time:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Other Tab, if needed.
3) Touch the Track Vector Time Button to display the Time Selection Buttons in the 'Map
Track Vector Time' Window.
4) Scroll the list, if needed, and touch a Time Selection Button to select the look-ahead time.
Selecting fuel reserves time:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Other Tab, if needed.
3) Touch the Fuel RNG (RSV) Time Button to display the keypad.
4) Use the keypad and touch the Enter Button to enter the fuel reserves time.
Selecting the lat/lon line maximum range:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Other Tab, if necessary.
