Or:
1) From PFW Home, touch PFD Map Settings.
2) In the Overlays Tab, touch the Traffic Settings Button.
3) Touch the Map Settings Button.
4) Touch the Labels button to enable/disable the display of traffic labels on navigation
maps.
5) To change the map maximum navigation map range to show traffic symbols, touch the
Symbols Button, then scroll as needed and touch a button for the desired range.
6) To change the map maximum navigation map range to show traffic labels, touch the
Labels Button, then scroll as needed and touch a button for the desired range.
Enabling/disabling the Traffic Inset Map on the PFD:
With the PFW in Full Mode, press the Traffic Map Softkey
Or:
From PFW Home, touch Traffic Map Button.
Showing the HSI Traffic Map:
1) From PFW Home, touch PFD Map Settings.
2) Touch the Layout Button.
3) Touch the HSI Traffic Button.
Or:
1) On the PFW, press the PFD Map Settings Softkey.
2) Press the Map Layout Softkey.
3) Press the HSI Traffic Softkey.
Enabling/disabling traffic overlay on PFD navigation maps:
1) With the Inset Map or HSI Map displayed, press the Map/HSI Softkey.
2) Press the Traffic Softkey to enable/disable the traffic overlay.
3) Press the Back Softkey to return to the top-level PFD softkeys.
ADS-B TRAFFIC
OPERATION
Enabling/disabling the display of ADS-B traffic:
1) From MFW Home, touch Traffic > Traffic Settings.
Or:
a) From MFW Home, touch Map > Map Selection > Map Settings.
b) Touch the Traffic Settings Button on the Sensor Tab.
Or:
