a) From PFW Home, touch PFD Map Settings.
b) Touch the Traffic Settings Button.
2) Touch the ADS-B Display Button.
Displaying Motion Vectors
Selecting a Motion Vector display:
1) From MFW Home, touch Traffic > Traffic Settings.
2) Touch the Motion Vector Button.
3) Touch a button to select the desired Motion Vector display mode: Off, Absolute, or
Relative.
4) To change the duration of time used to forecast motion vectors, touch the Vector
Duration Button.
5) Touch a button for the desired duration: 30SEC, 1MIN, 2MIN, or 5MIN.
Additional Traffic Displays
Showing additional traffic information:
1) From MFW Home, touch Traffic > Traffic Settings.
2) Touch the Target Selection Button.
3) Turn the upper knob. A cyan border appears on the first selected traffic symbol.
Additional information appears in a window in the lower-left corner of the ‘Traffic Map’
Pane.
4) To select a different aircraft symbol, turn the upper knob.
5) When finished, touch the Target Selection Button again to disable the button.
Customizing traffic display on the navigation maps:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Traffic Settings Button.
4) Touch the Map Settings Button.
5) Touch the Labels button to enable/disable the display of traffic labels on navigation
maps.
6) To change the map range above which the system removes traffic symbols from the
display, touch the Symbols Button, then scroll to and touch to select a map range above
which the system will remove the traffic symbols.
7) To change the map range at which the system removes traffic labels from the display
(such as, touch the Labels range button, then scroll to and touch to select a map range
above which the system removes traffic labels from the display.
Or:
