Selecting the preferred charts source:
1) From MFW Home, touch Charts > Chart Selection > Charts Options.
2) Ensure the desired chart source is available (indicated by a green check mark in the ‘Dual
Charts Status’ Window). When the database age is beyond the disable date, an amber
exclamation mark is displayed.
3) Touch the Preferred Source Button.
4) Touch either ChartView or FliteCharts to set as the preferred chart source. The current
selection is then displayed on the Preferred Source Button.
CHARTVIEW (OPTIONAL)
Selecting charts using the ‘Charts’ Screen:
1) From MFW Home, touch Charts > Chart Selection.
2) The airport for which charts will be displayed is shown at the top of the ‘Charts’ Screen.
Touch the Airport Button to enter another airport.
3) Touch the Info Tab to display the airport information selection buttons for the selected
airport.
a) Touch the Departure Tab to display a list of possible departures for the selected
airport.
b) Touch the Arrival Tab to display a list of possible arrivals for the selected airport.
c) Touch the Approach Tab to display a list of possible approaches for the selected
airport.
4) Touch the desired information button in any of these lists to display the applicable chart
on the selected display pane.
5) Touch the Charts Options Button to select the desired display option for the selected
chart.
6) Touch All to display the complete Airport Diagram. Fit Width displays the full width of
the Airport Diagram. Plan displays only the diagram portion of the chart. Minimums
displays only the approach minimums on an approach chart. Profile displays only
the descent profile on the approach chart. Header displays the chart header. Only
appropriate views are available for the selected chart.
7) Touch the Back Button to return to the ‘Charts’ Screen.
Zooming-in, zooming-out, rotating, and panning the displayed chart:
1) From MFW Home, touch Charts > Chart Selection.
2) Select the desired chart for display in the selected pane.
3) Push the lower knob. The ‘Charts Pan/Zoom Control’ Screen is displayed on the
Touchscreen Controller.
4) Turn the lower knob, or use the pinch-and-zoom feature on the Touchpad to adjust the
chart zoom.
