Entering the Runway Required distance for emergency return:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the EMER Return Tab.
3) Touch the Runway Required Button to display the keypad.
4) Use the keypad to enter the required landing distance.
5) Touch the Enter Button to accept the entry, and return to the EMER Return Tab.
LANDING DATA
DEST TAB
Manually selecting an destination airport and runway on the 'Landing Data' Screen:
1) From MFW Home, touch PERF > Landing Data to display the DEST Tab.
2) Touch the Destination Airport Button (may be displayed as six cyan dashes if empty) to
display the keypad.
3) Use the keypad to enter the destination airport.
4) Touch the Enter Button to accept the entry, and return to the 'Landing Data' Screen.
5) Touch the Runway Button to display the 'Select Runway' Screen.
6) Touch the desired Runway Selection Button, and return to the 'Landing Data' Screen.
Accessing the 'Weight and Fuel' Screen from the DEST Tab:
1) From MFW Home, touch PERF > Landing Data to display the DEST Tab.
2) Touch the Weight and Fuel Button to display the 'Weight and Fuel' Screen.
Loading data for emergency return:
1) From MFW Home, touch PERF > Landing Data.
2) Touch the Load Emergency Return Button. 'Load emergency return data for landing?'
is displayed.
3) Touch the OK Button to copy the data for emergency return to the 'Landing Data' Screen.
Runway Tab
Manually entering landing runway available distance:
1) From MFW Home, touch PERF > Landing Data.
2) Touch the Runway Tab.
3) Touch the Runway Available Button to display the 'Landing Distance Available' Screen.
4) Enter or change the landing runway available distance:
a) Touch the Land and Hold Short Button to display a list of intersections and LAHSO
buttons. Each button displays the name of the intersecting runway and LAHSO
designation (if available), and the landing distance available before that intersection/
LAHSO point.
