2) Touch the Auto Request Button.
3) From the selection window, touch an Auto Update Request Rate Button to select the
desired weather request update interval in minutes or touch the Off Button to disable
automatic Connext Data Requests.
WEATHER PRODUCT OVERVIEW
NEXRAD (SiriusXM)
WARNING: Do not use the indicated data link weather product age to ascertain the
age of the weather information shown by the data link weather product. Due to time
delays inherent in gathering and processing weather data for data link transmission,
the weather information shown by the data link weather product may be older than
the indicated weather product age.
Displaying NEXRAD weather information on the ‘SiriusXM Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather >
SiriusXM Settings.
2) Touch the NEXRAD Button in the ‘Background’ Window to enable/disable the display of
NEXRAD information.
Changing the NEXRAD coverage area on the ‘SiriusXM Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather >
SiriusXM Settings.
2) Touch the NEXRAD Settings Button. The ‘NEXRAD Options’ Window appears.
3) Touch the NEXRAD Type Button.
4) Touch the Composite Reflectivity CONUS or Base Reflectivity All Regions Button, or
touch Back or Home to exit without changing the coverage area.
Displaying NEXRAD weather information on the ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the NEXRAD Button in the ‘Overlays’ Window to enable/
disable the display of the NEXRAD weather product on the ‘Navigation Map’ Pane.
Changing the NEXRAD coverage area on the ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the NEXRAD Settings Button.
4) Touch the NEXRAD Type coverage Button (displaying either ‘Composite Reflectivity’ or
‘Base Reflectivity’ in cyan).
