5) Touch the Composite Reflectivity CONUS or Base Reflectivity All Regions Button, or
touch Back or Home to exit without changing the coverage area.
Displaying SiriusXM NEXRAD weather information (PFD Inset Map or HSI Map):
1) If necessary, enable the Inset Map or HSI Map.
2) From PFW Home, touch PFD Map Settings.
3) Scroll in the Overlays Tab and touch the NEXRAD Button.
Or:
1) Press the PFD Map Settings Softkey.
2) Press the WX Overlay Softkey until SiriusXM is displayed in cyan. Each press cycles
through an available option, displayed in cyan. When ‘SiriusXM’ is displayed, SiriusXM
NEXRAD is enabled. When ‘Off’ is displayed, SiriusXM NEXRAD data is disabled.
Changing the SiriusXM NEXRAD coverage area (PFD Inset Map or HSI Map):
1) From PFW Home, touch the PFD Map Settings Button.
2) Scroll in the Overlays Tab, and touch the NEXRAD Settings Button.
3) Touch the NEXRAD Type Button.
4) Touch the Composite Reflectivity CONUS or Base Reflectivity All Regions Button, or
touch Back or Home to exit without changing the coverage area.
Or:
1) Press the PFD Map Settings Softkey.
2) Press the Data Link Settings Softkey.
3) Press the NEXRAD Softkey. Each selection of the softkey changes the source ‘COMP’ or
‘Base’, which is displayed in cyan on the softkey.
Displaying Time-Lapse NEXRAD Animation on the ‘SiriusXM Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather >
SiriusXM Settings.
2) If not selected, touch the NEXRAD Button in the ‘Background’ Window to enable the
display of NEXRAD.
3) Touch the NEXRAD Settings Button.
4) Touch the Animation Button to enable/disable the animation.
5) When finished, touch Back or Home.
Displaying Time-Lapse NEXRAD Animation on the ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll if necessary and touch the NEXRAD Settings Button.
4) Touch the NEXRAD Animation Button to enable/disable the animated NEXRAD
information.
