2) Touch the Option 1 Button to display direction arrows with headwind and crosswind
components or touch the Option 2 Button to display wind direction arrow and speed.
Or:
1) Press the PFD Settings Softkey.
2) Press the Other PFD Settings Softkey.
3) Press the Wind Softkey.
4) Press desired wind option softkey ( ñ DEG KT, £ñ KT, or Off) to change how wind data
is displayed.
TIMER
Setting the Timer:
1) From PFW Home, touch the Timers Button.
2) Touch an existing timer button or Add Timer Button.
3) Input the desired time using the numeric keypad, then touch the Enter Button or push
the upper knob.
4) Touch the Up or Down Button.
5) To start timer, touch the Start Button. When the timer is active, the button changes to a
Stop Button.
6) To stop the timer, touch the Stop Button.
7) To reset the timer, touch the Reset Button.
PFD ANNUNCIATIONS AND ALERTING FUNCTIONS
MINIMUM ALTITUDE ALERTING
Setting the Minimum Descent Altitude/Decision Height (MDA/DH) Bug:
1) From PFW Home, touch Minimums.
Or:
From MFW Home, touch Utilities > Minimums.
2) On the Minimums Screen, touch the Minimums Button.
3) To set the MDA/DH bug, touch the Baro, or Temp Comp Buttons. To disable Minimums,
touch the Off Button.
4) If Temp Comp was selected, and the destination temperature was not entered previously,
the Destination Temp Screen appears. Enter the destination temperature using the
keypad or large and small knobs, then touch the Enter Button or push the small upper
knob. If the temperature is negative, touch the ± Button if necessary in order to place a
minus sign in front of the temperature datafield.
5) Enter the MDA/DH altitude using the keypad or the large/small upper knob. When
finished, touch the Enter Button or push the small upper knob.
