Level setting larger than the Current MFD Backlight Level will cause the display to remain
in Night Mode longer. Adjusting the Threshold Level setting smaller than the Current
MFD Backlight Level will cause the display to change to Day Mode sooner.
FLITECHARTS (OPTIONAL)
Selecting charts using the ‘Charts’ Screen:
1) From MFW Home, touch Charts > Chart Selection.
2) The airport for which charts will be displayed is shown at the top of the ‘Charts’ Screen.
Touch the Airport Button to enter another airport.
3) Touch the Info Tab to display the airport information selection buttons for the selected
airport.
a) Touch the Departure Tab to display a list of possible departures for the selected
airport.
b) Touch the Arrival Tab to display a list of possible arrivals for the selected airport.
c) Touch the Approach Tab to display a list of possible approaches for the selected
airport.
4) Touch the desired information button in any of these lists to display the applicable chart
on the selected display pane.
5) Touch the Charts Options Button to select the desired display option for the selected
chart.
6) Touch Fit Width to display the full width of the chart.
7) Touch the Back Button to return to the ‘Charts’ Screen.
Zooming-in, zooming-out, rotating, and panning the displayed chart:
1) From MFW Home, touch Charts > Chart Selection.
2) Select the desired chart for display in the selected pane.
3) Push the lower knob on the Touchscreen Controller. The ‘Charts Pan/Zoom Control’
Screen is displayed.
5) Move a finger along the Touchpad, or turn the upper knobs to pan the displayed chart.
6) Touch the Rotate buttons to rotate the chart clockwise or counter-clockwise, as indicated
on the button. Each touch of the button rotates the chart 90 degrees in the designated
direction.
Selecting airport diagrams from the ‘Nearest Airports’ Screen:
1) From MFW Home, touch Nearest > Airport.
2) Touch the desired airport button.
3) Touch the Airport Chart Button. The Info Tab selections are displayed on the
Touchscreen Controller and the Airport Diagram is displayed on the selected display pane.
