Garmin CIRRUS PERSPECTIVE TOUCH+ - Traffic Annunciations

Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin
190-02954-01 Rev. A 207
Annunciations & Alerts
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
Alert Cause
‘TAWS’ Pane Annunciation(s)
TAWS Alert
Types
Not Available
TAWS System Test Fail; Terrain, Airport
Terrain or Obstacle database unavailable
or invalid on all displays; software
mismatch among displays; TAWS audio
fault.
TAWS FAIL
and
TAWS FAIL
FLTA, PDA
MFW Terrain or Obstacle database
unavailable or invalid. TAWS operating
with PFD Terrain or Obstacle databases.
No GPS position.
TAWS N/A
and
NO GPS POSITION
FLTA, PDA, VCO
Excessively degraded GPS signal, or out
of database coverage area.
TAWS N/A
FLTA, PDA
TAWS-B Abnormal Status Alerts
TRAFFIC ANNUNCIATIONS
Traffic System
Mode
Traffic Map Mode Annunciation
Traffic Overlay
Status Icon
Operating TAS: OPERATING
Standby
TAS: STANDBY
(also shown in white in center of ‘Traffic Map’
Pane)
Failed
1
TAS: FAILED
TAS Modes
‘Traffic Map’ Pane
Center Annunciation
Description
NO DATA System is not receiving any data from the traffic unit.
