4) Touch the Clear Stormscope Lightning Button.
5) When finished, touch Back or Home.
Selecting a maximum Stormscope map range on ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the Stormscope Lightning Settings Button.
4) Touch the Stormscope Button (current range setting displayed in cyan).
5) Scroll as needed and touch a desired map range setting from the list.
VERTICAL SITUATION DISPLAY TERRAIN
Enabling/Disabling VSD Inset Window:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Inset Window Tab.
3) Touch the VERT Situation Display Button to enable/disable the VSD Inset Window.
Enabling/disabling Relative Terrain information in the VSD and ‘Navigation Map’ Pane:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Terrain Button.
4) Touch either the Absolute, Relative, or Absolute + Relative Button to enable the
display of Terrain information on the ‘Navigation Map’ Pane and VSD, or touch the Off
Button to remove this information.
Enabling/disabling Point Obstacle information in the VSD and ‘Navigation Map’ Pane:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Land Tab.
3) Touch the Point Obstacle Button to enable/disable the display of Point Obstacle
information on the ‘Navigation Map’ Pane and VSD.
Selecting a Point Obstacle information range in the VSD and ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Land Tab.
3) Touch the Point Obstacle Settings Button.
4) Touch the Point Obstacles Button (current range setting displayed in cyan).
5) Scroll as needed and touch a desired map range setting from the list.
Changing the Vertical Situation Display Mode:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Inset Window Tab.
