Selecting a Stormscope operating mode (PFD maps):
1) From PFW Home, touch PFD Map Settings.
2) If not selected, touch either the HSI Map or Inset Map Button to allow for selection of
map overlays.
3) Touch the Stormscope Lightning Settings Button.
4) Touch either the Cell or Strike Buttons.
Clearing Stormscope Lightning (PFD maps):
1) From PFW Home, touch the PFD Map Settings Button.
2) If not selected, touch either the HSI Map or Inset Map Button to allow for selection of
map overlays.
3) Touch the Stormscope Lightning Settings Button.
4) Touch the Clear Stormscope Lightning Button.
Selecting a maximum Stormscope map range for the PFD maps:
1) From PFW Home, touch PFD Map Settings.
2) If not selected, touch either the HSI Map or Inset Map Button to allow for selection of
map overlays.
3) Scroll as needed and touch the Stormscope Lightning Settings Button.
4) Touch the Stormscope Button (current range setting displayed in cyan).
5) Scroll as needed and touch a desired map range setting from the list.
Enabling/disabling Stormscope information on ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the Stormscope Lightning Button.
Selecting a Stormscope mode for ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the Stormscope Lightning Settings Button.
4) Touch either the Cell Button or the Strike Button. Button annunciator is green for
currently selected mode.
5) When finished, touch Back or Home.
Clearing Stormscope information on ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the Stormscope Lightning Settings Button.
