FLIGHT PLAN DISPLAY
Displaying/removing the flight plan preview:
1) For the active flight plan: From MFW Home, touch Flight Plan > Flight Plan Options.
Or:
For the standby flight plan: From MFW Home, touch Flight Plan > Standby Flight Plan
> Flight Plan Options.
Or:
For the stored flight plan:
a) From MFW Home, touch Flight Plan > Flight Plan Options > Flight Plan Catalog
to display the 'Flight Plan Catalog' Screen.
b) Scroll the list if needed and touch a Stored Flight Plan Button to display the 'Catalog
Options' Window.
c) Touch the Edit Button to display the 'Edit Stored Flight Plan' Screen.
d) Touch the Flight Plan Options Button.
2) Touch the Preview FPL Button. A preview of the flight plan is shown on the active
display pane.
3) To view a flight plan segment:
a) Touch the Back Button.
b) Scroll as needed, and touch the selection button corresponding to the desired
segment of the flight plan.
c) Touch the Back Button to return to the flight plan preview.
4) Touch the Preview FPL Button again or return to the 'MFW Home' Screen to disable the
Preview FPL Button and remove the preview from the display.
Displaying/removing the Flight Plan Text Inset:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Inset Window Tab.
3) Touch the Flight Plan Text Button to display/remove the active flight plan text on the
'Navigation Map' Pane.
4) Waypoint distances shown on the Flight Plan Text Inset may be set as leg to leg distances
or cumulative distance by selecting the CUM Button or Leg-Leg Button next to the
Flight Plan Text Button.
Displaying/removing the Flight Plan Progress Inset:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Inset Window Tab.
3) Touch the Flight Plan Progress Button to display/remove the flight plan progress inset.
