4) The first time temperature compensation is enabled, the ‘Destination Temp’ Screen is
displayed. Use the keypad and the Enter Button to select the temperature at the airport.
Touch the Back Button to return to the ‘Temp Compensation’ Screen. If temperature
compensation was previously enabled, the previous entry for destination temperature is
automatically entered.
5) To edit the airport temperature, touch the Temp at Dest Button and use the keypad and
the Enter Button to select the temperature at the airport.
Entering a temperature compensated minimum into an approach:
1) From MFW Home, touch PROC > Approach to display the ‘Approach Selection’ Screen.
Or:
a) From MFW Home, touch Flight Plan.
b) Touch the Approach Header Button to display the ‘Approach Options’ Window.
c) Touch the Edit Approach Button to display the ‘Approach Selection’ Screen.
2) Touch the Minimums Button to display the ‘Minimums’ Screen.
3) Touch the Minimums Button to display the ‘Minimums Source’ Window.
4) Touch the Temp Comp Button. If necessary, use the keypad and touch the ENT Button
to enter the destination airport temperature. If temperature compensation was previously
enabled, the previous entry for destination temperature is automatically entered.
5) If not already entered, use the keypad to select the minimums altitude.
6) Touch the Enter Button to return to the ‘Approach Selection’ Screen.
WEIGHT AND BALANCE
Selecting the Weight and Balance Display Type:
1) From MFW Home, touch PERF > Weight and Balance.
2) Display the full pane or the desired half pane:
To view the full pan, if necessary, touch the Full Button to display a full sized display
pane showing the Station vs. Weight Box, 'Aircraft Weight and Balance' Box, and
'Aircraft Load' Box.
Or:
a) To view a half pane, touch the Half Button on the Button Bar, if required.
b) Touch the Display Button to display the 'Select Display Type' Window.
c) Touch the button corresponding to the desired display type.
Entering the aircraft load weights:
1) From MFW Home, touch PERF > Weight and Balance.
2) Touch the Aircraft Loading Tab to display the aircraft load weight buttons.
3) Touch an aircraft load weight button to display the keypad.
