Selecting an absolute terrain data range:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Sensor Tab, if necessary.
3) Touch the Terrain Settings Button. A window is displayed providing terrain functions
allowed by the system.
4) Touch the Map Settings Button. A window is displayed providing terrain settings.
5) Touch the Terrain Button to display the 'Map Terrain Range' Window.
6) Scroll the list if necessary to find the desired range, and touch the Range Button.
Displaying/removing the absolute terrain scale:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Sensor Tab, if necessary.
3) Touch the Terrain Settings Button. A window is displayed providing terrain functions
allowed by the system.
4) Touch the Map Settings Button. A window is displayed providing terrain settings.
5) Touch the Absolute Terrain Scale Button to display/remove the absolute terrain scale.
MAP SYMBOLS
Displaying/removing a land or aviation symbol type:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Aviation Tab or the Land, Tab, if necessary.
3) Scroll the list to find the desired item.
4) Touch the annunciator button to display/remove the symbol type.
Displaying and removing airspace altitude labels:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Aviation Tab.
3) Touch the Airspaces Settings Button to display the 'Airspace Settings' Window.
4) Touch the Airspace Altitude Labels Button to display/remove the labels.
Selecting an Aviation or Land item maximum range:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Aviation Tab or Land Tab, if necessary.
3) Scroll the list to find the desired item.
4) If necessary, touch the Settings Button to display the Range Buttons.
5) Touch the Range Button to display the range choices.
6) Touch a Range Selection Button to select the maximum range.
7) Repeat Steps 3 through 6 as necessary.
