Syncing charts to current phase of flight:
1) From MFW Home, touch Charts > Chart Selection.
2) From the ‘Charts’ Page, press the SYNC POF Button to cause the chart applicable to the
current phase of flight to be displayed.
Selecting Night, Day, or Auto view:
1) From MFW Home, touch Charts > Chart Selection > Charts Options.
2) Touch the Light Mode Button.
3) Touch the Night, Day, or Auto Button. When Auto is selected, the display will change
to the appropriate day or night setting, dependent on ambient lighting.
4) With ‘Auto’ selected, touch the Threshold Button. The ‘Auto Light Mode Threshold’
Window is displayed.
5) Move the slider left or right to set the desired threshold. Setting the Threshold Level
percentage to the same percentage shown as the Current MFD Backlight Level will cause
the Day/Night view to switch at the current backlight setting. Adjusting the Threshold
Level setting larger than the Current MFD Backlight Level will cause the display to remain
in Night Mode longer. Adjusting the Threshold Level setting smaller than the Current
MFD Backlight Level will cause the display to change to Day Mode sooner.
IFR/VFR CHARTS
Selecting the chart to display:
1) From MFW Home, touch Map > Map Selection.
2) Touch the desired Chart Button (VFR, IFR Low, or IFR High).
Modifying the VFR, IFR Low, and IFR High chart settings:
1) From MFW Home, touch Map > Map Selection.
2) Touch the desired Chart Button. The selected chart is displayed on the active display
pane, and the button on the Touchscreen Controller becomes the Chart Settings Button
(VFR Settings Button, IFR Low Settings Button, or IFR High Settings Button).
3) Touch the Chart Settings Button to display the applicable settings screen (‘VFR Charts
Settings’ Page or ‘IFR Charts Settings’ Page.
Selecting Day, Night, or Auto View:
1) From MFW Home, touch Map > Map Selection > VFR, IFR Low, or IFR High.
2) Touch the applicable settings button: VFR Settings, IFR Low Settings, or IFR High
Settings.
3) Touch the Light Mode Button.
4) Touch the Day, Night, or Auto Button. When Auto is selected, the display will change
to the appropriate day or night setting, dependent on ambient lighting.
