GARMIN SVT™ (SYNTHETIC VISION TECHNOLOGY)
SVT OPERATION
Enabling/Disabling SVT Modes:
1) From PFW Home, touch PFD Settings > Synthetic Vision.
2) Touch the Auto, Flight, or Off Button.
Or:
1) Press the PFD Settings Softkey.
2) Press the SVT Mode Softkey.
3) Press the Auto, Flight, or Off Softkey.
Enabling/Disabling SVT Settings (SVT must be enabled):
1) From PFW Home, touch the PFD Settings > Settings.
2) Touch the Pathways, Runway Locator, Airport Signs, or Wire Buttons.
Or:
1) Press the PFD Settings Softkey.
2) Press the SVT Settings Softkey.
3) Press the Pathways, Runway Locator, Airport Signs, or Wire Softkeys.
Enabling/Disabling SVT Horizon Heading (SVT must be enabled):
1) From PFW Home, touch PFD Settings > Horizon Heading.
Or:
1) Press the PFD Settings Softkey.
2) Press the Attitude Instruments Softkey.
3) Press the Horizon Heading Softkey.
FIELD OF VIEW
Enabling or Disabling the Field of View Indication:
1) From MFW Home, touch Map Selection > Map Settings.
2) Touch the Other Tab.
3) Scroll and touch the Field of View Button to enable/disable field of view display.
SUPPLEMENTAL FLIGHT DATA
WIND DATA
Displaying Wind Data:
1) From PFW Home, touch PFD Settings > Wind.
