3) Move the pointer using the Touchpad to the desired reference location. A dashed
Measurement Line is drawn from the aircraft present position to the location of the
Measure Pointer. The latitude/longitude, distance, bearing and elevation data of the
Measure Pointer are displayed at the top left of the map.
4) Touch the Select Ref Button to set the Measure Pointer location as the new reference
point for measurement. The dashed Measurement Line is erased.
5) Move the pointer using the Touchpad to the desired location. A dashed Measurement
Line is drawn from the reference point to the location of the Measure Pointer. The
latitude/longitude, distance, bearing and elevation data of the Measure Pointer are
displayed at the top left of the map.
6) Repeat Steps 3 through 5 to measure between other points.
7) To exit the Measure Bearing/Distance function, push either knob, or touch the Back
Button.
ABSOLUTE TERRAIN
Displaying/removing absolute terrain data:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Sensor Tab, if necessary.
3) Touch the Terrain Button to display the 'Map Terrain Displayed' Window.
4) Touch the Absolute Button to display absolute terrain data, or touch the Off Button to
remove absolute terrain data.
Displaying/removing absolute terrain data on the PFW Map:
1) From PFW Home, touch PFD Map Settings.
2) Touch the Terrain Button to display the 'Inset Map Terrain Displayed' Window.
3) Display or remove absolute terrain data:
Touch the Absolute Button to display absolute terrain data on the PFW Map.
Or:
Touch the Off Button to remove absolute terrain data from the PFW Map.
Or:
1) Press the PFD Map Settings Softkey on the PFW.
2) Display or remove absolute terrain data:
Press the Terrain Softkey until 'Absolute' is shown to display absolute terrain data on
the PFW Map.
Or:
Press the Terrain Softkey until 'Off' is shown to remove absolute terrain data from
the PFW Map.
