Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin
190-02954-01 Rev. A 209
Annunciations & Alerts
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
Traffic Status
Banner
Annunciation
Description
TA OFF SCALE
A Traffic Advisory is outside the selected display range.
1
Annunciation is removed when traffic comes within the selected display range.
TA X.X ± XX ↕
System cannot determine bearing of Traffic Advisory.
2
Annunciation indicates distance in nm, altitude separation in hundreds of feet, and
altitude trend arrow (climbing/descending).
TRFC FAIL
Traffic unit has failed (unit is self-reporting a failure or sending incorrectly
formatted data).
NO TRFC DATA Data is not being received from the traffic unit.
1
Shown as symbol on ‘Traffic Map’ Pane
2
Shown in center of ‘Traffic Map’ Pane.
Traffic Status Annunciations
AFCS ANNUNCIATIONS
Condition Annunciation Description
Pitch Failure
PTCH
Pitch axis control failure; autopilot inoperative
Roll Failure
ROLL
Roll axis control failure; autopilot inoperative
Pitch Trim Failure
(or stuck MEPT
Switch)
PTRM
If autopilot is engaged, take control of the aircraft and
disengage autopilot
If autopilot is disengaged, move MEPT switches separately to
unstick
Yaw Damper Failure
YAW
Yaw damper control failure
System Failure
AFCS
Autopilot and MEPT are unavailable; Flight director may still
be available
Elevator Mistrim
Down
¤ELE
Pitch servo providing sustained force in the indicated
direction
- May indicate a failure of the pitch-trim adapter or trim
system
Elevator Mistrim Up
£ELE
Aileron Mistrim
Right
AILñ
Roll servo providing sustained force in the indicated direction
Aileron Mistrim Left
œAIL
