‘Traffic Map’ Pane
Center Annunciation
Description
DATA FAILED
System is receiving data from the traffic unit, but the unit is reporting a
failure.
FAILED The traffic unit is sending invalid data to the system.
TAS Failure Annunciations
Traffic Status Banner
Annunciation
Description
TA OFF SCALE
A Traffic Advisory is outside the selected display range.
1
Annunciation is removed when traffic comes within the selected
display range.
TA X.X ± XX ↕
System cannot determine bearing of Traffic Advisory.
2
Annunciation indicates distance in nm, altitude separation in
hundreds of feet, and altitude trend arrow (climbing/descending).
TRFC FAIL
The traffic unit has failed (unit is self-reporting a failure or sending
incorrectly formatted data).
2
NO TRFC DATA
Data is not being received from the traffic unit.
1
Shown as symbol on ‘Traffic Map’ Pane.
2
Shown in center of ‘Traffic Map’ Pane.
TAS Traffic Status Annunciations
‘Traffic Map’ Pane
Center Annunciation
Description
NO DATA Data is not being received from the traffic unit.
DATA FAILED
Data is being received from the traffic unit, but the unit is self-reporting a
failure.
FAILED Incorrect data format received from the traffic unit.
Traffic Failure Annunciations
