5) When finished, touch Back or Home.
Displaying Time-Lapse NEXRAD Animation on the PFD Inset Map:
1) If necessary, enable the Inset Map.
2) From PFW Home, touch the PFD Map Settings Button.
3) Scroll and touch the NEXRAD Settings Button.
4) Touch the NEXRAD Animation Button to enable/disable the animated NEXRAD
information on the Inset Map
Or:
1) Press the PFD Map Settings Softkey.
2) Press the Data Link Settings Softkey.
3) Press the NEXRAD Animation Softkey.
NEXRAD (FIS-B)
Enabling/Disabling FIS-B weather information on the ‘FIS-B Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > FIS-B Weather > FIS-B
Settings.
2) Touch the Enable FIS-B Button in the ‘FIS-B Data Status’ Window to enable/disable the
display of FIS-B Weather information.
Displaying the NEXRAD weather product on the ‘FIS-B Weather; Pane (CONUS or Re-
gional):
1) From MFW Home, touch Weather > Weather Selection > FIS-B Weather > FIS-B
Settings.
2) Touch the CONUS NEXRAD or Regional NEXRAD Buttons in the ‘Overlays’ Window.
Displaying FIS-B NEXRAD weather information on the ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the NEXRAD Button.
4) Touch the CONUS, Regional, or Combined Button to enable/disable the display of the
NEXRAD weather product on the ‘Navigation Map’ Pane.
Displaying FIS-B NEXRAD weather information (PFD Inset Map or HSI Map):
1) If necessary, enable the Inset Map or HSI Map.
2) From PFW Home, touch PFD Map Settings.
3) Scroll in the Overlays Tab and touch the NEXRAD Button.
Or:
1) Press the PFD Map Settings Softkey.
