2) Press the WX Overlay Softkey until FIS-B is displayed in cyan. Each press cycles through
an available option, displayed in cyan. When ‘FIS-B’ is displayed, FIS-B NEXRAD is
enabled. When ‘Off’ is displayed, FIS-B NEXRAD data is disabled.
Changing the FIS-B NEXRAD coverage area (PFD Inset Map or HSI Map):
1) From PFW Home, touch the PFD Map Settings Button.
2) Scroll in the Overlays Tab, and touch the NEXRAD Button.
3) Touch the either CONUS, Regional, or Combined Button for the desired FIS-B NEXRAD
coverage data.
Or:
1) Press the PFD Map Settings Softkey.
2) Press the Data Link Settings Softkey.
3) Press the NEXRAD Softkey to select between ‘CONUS’, ‘Regional’, or ‘Combined’ FIS-B
NEXRAD Coverage data.
Precipitation (Garmin Connext)
Displaying Garmin Connext Radar information on the ‘Connext Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > Connext Weather >
Connext Settings.
2) Touch the Radar Button in the ‘Overlays’ Window.
Displaying Garmin Connext Radar information on the ‘Navigation Map’ Panes:
1) From MFW Home, Touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor tab.
3) Scroll if needed and touch the Connext Radar Button
Displaying Connext Radar weather information (PFD Inset Map or HSI Map):
1) If necessary, enable the Inset Map or HSI Map.
2) From PFW Home, touch PFD Map Settings.
3) Scroll in the Overlays Tab and touch the Connext Radar Button.
Or:
1) Press the PFD Map Settings Softkey.
2) Press the WX Overlay Softkey until Connext is displayed in cyan. Each press cycles
through an available option, displayed in cyan. When ‘Connext’ is displayed, Connext
Radar is enabled. When ‘Off’ is displayed, Connext Radar is disabled.
Enabling/Disabling Echo Tops information:
1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather >
SiriusXM Settings.
2) Touch the Echo Tops Button in the ‘Background’ window.
