Cloud Tops (SiriusXM/FIS-B)
Enabling/Disabling Cloud Tops information on the ‘Data Link Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > ‘Data Link’ Weather >
‘Data Link’ Weather Settings.
2) Touch the Cloud Tops Button in the ‘Background’ Window (SiriusXM) or ‘Overlays’
Window (FIS-B).
Infrared Satellite (Garmin Connext)
Displaying Infrared Satellite information on the ‘Connext Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > Connext Weather >
Connext Settings.
2) Touch the IR Satellite Button in the ‘Overlays’ Window.
METARs and TAFs
Displaying METAR text on the ‘Data Link Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > ‘Data Link’ Weather >
‘Data Link’ Weather Settings.
2) Touch the METARs Button in the ‘Overlays’ Window. The system displays graphical
METAR flags at available reporting stations when METARs are enabled (button
annunciator is green).
3) To view METAR text, press the lower knob and move the map pointer with the large and
small upper knobs or Touchpad over a METAR flag. The system displays the original
METAR text near the METAR flag. If the display has not yet received the METAR text
associated with the selected flag, it displays “Waiting for METAR text.” until it receives
this information.
Displaying Graphical METAR information on ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Graphical METARs Button. The system displays METAR flags at available
reporting stations when METARs are enabled (button annunciator is green).
4) To view METAR text, press the lower knob and move the map pointer with the large and
small upper knobs or Touchpad over a METAR flag. The system displays the original
METAR text near the METAR flag. If the display has not yet received the METAR text
associated with the selected flag, it displays “Waiting for METAR text.” until it receives
this information.
Displaying METAR information (PFD Inset Map):
1) From PFW Home, touch PFD Map Settings.
2) Scroll and touch the Graphical METARs Button. METAR flags appear on the map.
Or:
