1) Press the PFD Map Settings.
2) Press the METAR Softkey.
3) If the PFD Inset Map is shown, use the upper and lower knobs on the Touchscreen
Controller to pan the Map Pointer over the desired METAR flag to view the original
METAR text. Note: METAR text is not available on the HSI map.
Viewing textual METAR/TAF information on the Airport Information Screen:
1) From MFW Home, touch Waypoint Info > Airport.
2) If the desired airport identifier and name already appears in the airport button near the
top of the screen, go to step 5.
3) Touch the airport button.
4) Enter the airport identifier using the keypad or the large and small upper knobs, then
touch the Enter Button or push the upper knob.
5) Touch the Weather Tab.
6) Touch a button for an available weather product (METAR Raw, METAR Decoded,
TAF Raw, TAF Decoded). If a button is subdued, that weather product is currently
unavailable for the selected airport.
7) Scroll as necessary to view the weather text. Note raw weather products may provide
additional information not present in the decoded version.
Data Link Lightning
Enabling/Disabling ‘Data Link’ Lightning information:
1) From MFW Home, touch Weather > Weather Selection > ‘Data Link’ Weather >
‘Data Link’ Weather Settings.
2) Touch the Lightning Button in the ‘Overlays’ Window.
Displaying ‘Data Link’ Lightning information on ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the ‘Data Link’ Lightning Button.
Displaying ‘Data Link’ Lightning information on PFD maps:
1) From PFW Home, touch PFD Map Settings.
2) If not selected, touch either the HSI Map or PFD Inset Map Button to access overlays
buttons.
3) Scroll if necessary in the Overlays Tab, and touch the ‘Data Link’ Lightning Button.
Or:
1) If necessary, enable the HSI Map or PFD Inset Map to access ‘Data Link’ softkeys.
2) Press the PFD Map Settings Softkey.
3) Press the Datalink Lightning Softkey.
