Winds Aloft
Displaying Winds Aloft data:
1) From MFW Home, touch Weather > Weather Selection > Data Link Weather > Data
Link Weather Settings.
2) Scroll as needed in the ‘Overlays’ Window and touch the Winds Aloft Button.
3) To change the selected winds aloft altitude, touch the Winds Aloft altitude button and
select the desired winds aloft altitude from the pop-up window.
Enabling/Disabling VSD (containing winds aloft data):
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Inset Window Tab.
3) Touch the VERT Situation Display Button to enable/disable the VSD Inset Window. If
the winds aloft weather product icon does not appear in the inset window, continue with
this procedure to enable winds aloft information.
4) Touch the VERT Situation Display Settings Button.
5) Touch the Winds Button. When enabled, the system displays the winds aloft weather
product inside the Vertical Situation Display.
Temperatures Aloft (SiriusXM)
Displaying Temperatures Aloft data on the ‘SiriusXM Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather >
SiriusXM Settings.
2) Scroll in the ‘Overlays’ Window and touch the Temps Aloft Button.
3) Touch the Temperatures Aloft altitude button (to the right of the Temps Aloft
annunciator button) and touch the desired altitude from which to display temperature
aloft data.
Storm Cell Movement (SiriusXM)
Enabling/Disabling Storm Cell Movement Information on the ‘SiriusXM Weather’ Pane:
1) From MFW Home, touch Weather > Weather Selection > SiriusXM Weather >
SiriusXM Settings.
2) Touch the Storm Cell Movement Button in the ‘Overlays’ Window.
Displaying Storm Cell Movement Information on ‘Navigation Map’ Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll as needed and touch the NEXRAD Settings Button.
4) Touch the Storm Cell Movement Button. When button annunciator is green, the system
shows Storm Cell Movement with the NEXRAD weather product on navigation map
panes. When button annunciator is gray, system will not show the Storm Cell Movement
weather product on navigation map panes.
