1) From PFW Home, touch PFD Map Settings.
2) In the Overlays Tab, touch the Traffic Settings Button.
3) Touch the Map Settings Button.
4) Touch the Labels button to enable/disable the display of traffic labels on navigation
maps.
5) To change the map maximum navigation map range to show traffic symbols, touch the
Symbols Button, then scroll as needed and touch a button for the desired range.
6) To change the map maximum navigation map range to show traffic labels, touch the
Labels Button, then scroll as needed and touch a button for the desired range.
Traffic Map Display Range
Selecting the ‘Traffic Map’ Pane display range:
1) From MFW Home, touch the Traffic > Traffic Settings Button.
2) Turn the lower knob clockwise to increase map range, or counter-clockwise to decrease
map range.
3) The following range options are available:
• 750 ft.
• 750 ft and 1500 ft.
• 1500 ft and 0.5 nm.
• 0.5 nm and 1 nm.
• 1 and 2 nm.
• 2 and 6 nm.
• 6 and 12 nm.
• 12 and 24 nm.
• 24 and 40 nm.
Viewing ADS-B Traffic Status:
1) From MFD Home, touch Utilities > Setup > ADS-B Status.
2) View the status of the traffic applications, then touch the Back Button or the Home
Button when finished.
