3) Touch one of the following buttons from the list:
• Unrestricted: All traffic is displayed from 9900 feet above and 9900 feet below the
aircraft.
• Above: Displays non-threat and proximity traffic from 9900 feet above the aircraft to
2700 feet below the aircraft. Typically used during climb phase of flight.
• Normal: Displays non-threat and proximity traffic from 2700 feet above the aircraft to
2700 feet below the aircraft. Typically used during enroute phase of flight.
• Below: Displays non-threat and proximity traffic from 2700 feet above the aircraft to
9900 feet below the aircraft. Typically used during descent phase of flight.
Additional Traffic Displays
Enabling/disabling display of traffic information on Navigation Map Panes:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Traffic Button.
Enabling/disabling the display of traffic information (HSI Map or Inset Map):
1) From PFW Home, touch PFD Map Settings.
2) Touch the Layout Button. If not selected, touch the HSI Map Button or Inset Map
Button to access the Overlays settings.
3) Touch the Traffic Button in the ‘Overlays’ Window to enable/disable the display of traffic
on the HSI Map or Inset Map.
Or:
1) Press the PFD Map Settings Softkey.
2) Press the Traffic Softkey.
Customizing traffic display on the navigation maps:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Traffic Settings Button.
4) Touch the Map Settings Button.
5) Touch the Labels button to enable/disable the display of traffic labels on navigation
maps.
6) To change the map range above which the system removes traffic symbols from the
display, touch the Symbols Button, then scroll to and touch to select a map range above
which the system will remove the traffic symbols.
7) To change the map range at which the system removes traffic labels from the display
(such as, touch the Labels range button, then scroll to and touch to select a map range
above which the system removes traffic labels from the display.
