1) Press the PFD Map Settings Softkey.
2) Press the Terrain Settings Softkey.
3) Press the Relative Softkey.
Customizing terrain and obstacle display on the ‘Navigation Map’ Pane:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Terrain Settings Button.
4) Touch the Map Settings Button.
5) The Terrain Button displays the maximum navigation map range to show relative terrain
information in cyan. To change this value, touch the Terrain Button.
6) Scroll as needed, and touch a maximum navigation map range to display relative terrain
information.
7) Touch the Back Button three times to return to the ‘Map Settings’ Screen.
8) Touch the Land Tab.
9) Touch the Point Obstacle Button to enable/disable the display of point obstacles on
navigation maps.
10) Touch the Point Obstacle Settings Button.
11) Touch the Point Obstacle Button.
12) The Point Obstacle Button displays the maximum map range to show point obstacles in
cyan. Touch this button to change the value.
13) Scroll as needed, and touch a maximum navigation map range to display point obstacle
information.
14) When finished, touch the Back Button or the Home Button.
Enabling/disabling Smart Obstacles Information on (Navigation Maps):
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Land Tab.
3) Touch the Point Obstacle Settings Button.
4) Touch the Smart Obstacles Button.
Controlling Absolute Terrain + Relative Terrain Information on the Navigation Map
Pane:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Terrain Button.
4) Touch the Absolute + Relative Button to enable Absolute + Relative Terrain feature, or
Off to remove terrain information.
Relative Terrain Legend
In-Air Legend
On-Ground Legend
DISPLAYING RELATIVE TERRAIN INFORMATION
Showing the Terrain Pane:
From MFW Home, touch the [Terrain] Button. [Terrain] can be Terrain-SVT, or TAWS.
Enabling/disabling aviation information on the Terrain Pane:
1) From MFW Home, touch the [Terrain] Button. [Terrain] can be Terrain-SVT, or TAWS.
2) Touch the Show Aviation Data Button to enable/disable aviation information (airports,
VORs, NDBs, Intersections) for the terrain pane.
Relative Terrain on the Navigation Maps
Controlling Relative Terrain Information (Navigation Map Panes):
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Touch the Terrain Button.
4) Touch the Relative Button to enable Relative Terrain, or Off to remove terrain
information.
Controlling Relative Terrain Information (Inset and HSI Map):
1) From PFW Home, touch PFD Map Settings.
2) If the Inset Map or HSI Map is not presently shown on the PFD, do the following:
a) Touch the Layout Button.
b) Touch the Inset Map Button to display the Inset Map, or touch the HSI Map Button
to display the HSI Map.
3) Touch the Terrain Button.
4) Touch the Relative Button to enable Relative Terrain, or Off to remove terrain
information.
Or:
