Garmin CIRRUS PERSPECTIVE TOUCH+ - Page 179

Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin
190-02954-01 Rev. A 153
Additional Features
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
Selecting required takeoff / landing distance using the ‘PERF’ Page:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the Origin Tab.
3) If not already selected, touch the Runway Button and select the takeoff runway.
4) Touch the Runway Tab. The ‘Runway Available’ Distance is automatically populated for
runways supported with PERF data.
5) Touch the Runway Required Button and adjust the required takeoff distance as
required.
Selecting required landing distance:
1) From MFW Home, touch the PERF > Landing Data.
2) Touch the DEST Tab (if not already selected).
3) Touch the Runway Button and select the landing runway.
4) Touch the Runway Tab. ‘The Runway Available’ is automatically populated for runways
supported with PERF data.
5) Touch Runway Required Button and adjust the required landing distance as required.
NOTE: While a missing or invalid SafeTaxi Database will reduce functionality, Surface-
Watch will remain operational. All SurfaceWatch alerting is based on the Navigation
Database. The SurfaceWatch Information Box will show only ‘On’ or ‘Approaching’
runway information if the SafeTaxi Database is missing or invalid or if the airport does
not have SafeTaxi diagrams.
Alert Description
SURFACEWATCH FAIL
(One or more inputs
invalid)
The GPS or WAAS position could be invalid, or is insufficient due to RAIM
position warning, loss of integrity, or the GPS horizontal protection level
exceeds the LNAV/VNAV horizontal alert limit (556.0 meters). Heading Input
could be invalid.
SURFACEWATCH
INHIBITED
(SurfaceWatch inhibited)
SurfaceWatch has been inhibited by the pilot. Aural and visual alerts are
inhibited. Functionality will automatically reset on a system restart.
SURFACEWATCH
DISABLED
(Too far north/south)
Issued when the aircraft is positioned north of N 87° latitude or south of S 87°
latitude.
