IP8820/IP8830/IP8840
Installer Guide
21
Jan 17 4:32
Enter Secondary DNS
0.0.0.0
Clear OK

Jan 17 4:32
MAC Address
00:40:5A:00:00:00
Clear OK

respond, the IP phone contacts a secondary DNS for FQDN resolution. This is an optional but
recommended setting.
To assign the Secondary DNS Address:
 Press the Settings (
) button. If the LCD Menu is locked, use the unlock procedure.
Refer to section 3.3
.
 Press the
digit, or move the cursor to 1.Network Configuration using the [Next]-
[Previous] softkeys and press the [OK] softkey.
 Press the
digit, or move the cursor to 6.Secondary DNS Address using the [Next]-
[Previous] softkeys and press the [OK] softkey.
 Input the Secondary DNS Address using the dial
pad and press the [OK] softkey to save your entry.
 Move to another parameter with the navigation
buttons and continue the session or press the
Settings (
) button to exit the configuration
session.
Changing the Secondary DNS Address requires a reboot of the IP phone; when you
leave the menu, you will receive a reboot notice. The IP phone must reboot to utilize
the new values entered.
3.4.7 MAC Address
IEEE specifications require manufacturers of data equipment to store a unique 6-byte MAC or
Ethernet address in the permanent memory of each network device.
To view the MAC Address:
 Press the Settings (
) button.
 Press the
digit, or move the cursor to 1.Network Configuration using the [Next]-
[Previous] softkeys and press the [OK] softkey.
 Press the
digit, or move the cursor to 7.MAC Address using the [Next]-[Previous]
softkeys and press the [OK] softkey.
 View the MAC Address of the IP phone.
 Move to another parameter with the navigation
buttons and continue the session or press the
Settings (
) button to exit the configuration
session.
3.4.8 VLAN Settings
VLAN settings define the Ethernet frame priority and VLAN identification in accordance with
IEEE 802.1p/Q standard. Separate VLAN tags are assigned for the IP Phone PC port and the
LAN (voice) port. With a VLAN Id assigned, only frames with the assigned Id are accepted, and
all SIP and voice frames sent by the IP8820, IP8830 and IP8840 include the VLAN Id assigned
to the LAN port.
