Genban IP8820 - VLAN Priority (PC)

IP8820/IP8830/IP8840
Installer Guide
23
Jan 17 4:32
VLAN ID (LAN)[0-4094]
0
Clear OK

Jan 17 4:32
VLAN Priority (PC)[0-7]
0
Clear OK

 Press the digit, or move the cursor to 1.Network Configuration using the [Next]-
[Previous] softkeys and press the [OK] softkey.
 Press the
digit, or move the cursor to 8.VLAN Settings using the [Next]-[Previous]
softkeys and press the [OK] softkey.
 Press the
digit, or move the cursor to 2.VLAN ID (LAN) using the [Next]-[Previous]
softkeys and press the [OK] softkey.
 Input the VLAN ID for the LAN port using the dial
pad and press the [OK] softkey to save your entry.
 Move to another parameter with the navigation
buttons and continue the session or press the
Settings (
) button to exit the configuration
session.
Changing the VLAN ID requires a reboot of the IP Phone; when you leave the menu,
you will receive a reboot notice. The IP Phone must reboot to utilize the new values
entered.
To disable VLANs, assign the VLAN ID as zero (0).
3.4.8.3 VLAN Priority (PC)
The VLAN Priority (PC) establishes the priority for Ethernet frames for the IP Phone PC port.
Setting the VLAN ID to zero (0) disables VLAN framing and the IP Phone uses only standard
Ethernet frames.
To assign the VLAN Priority for the PC port:
 Press the Settings (
) button. If the LCD Menu is locked, use the unlock procedure.
Refer to section 3.3
.
 Press the
digit, or move the cursor to 1.Network Configuration using the [Next]-
[Previous] softkeys and press the [OK] softkey.
 Press the
digit, or move the cursor to 8.VLAN Settings using the [Next]-[Previous]
softkeys and press the [OK] softkey.
 Press the
digit, or move the cursor to 3.VLAN Priority (PC) using the [Next]-
[Previous] softkeys and press the [OK] softkey.
 Input the VLAN Priority for the PC port using the
dial pad and press the [OK] softkey to save your
entry.
 Move to another parameter with the navigation
buttons and continue the session or press the
Settings (
) button to exit the configuration session.
Changing the VLAN priority for the PC port requires a reboot of the IP Phone; when you
leave the menu, you will receive a reboot notice. The IP Phone must reboot to utilize
the new values entered.
To disable VLANs, assign the VLAN ID as zero (0).
The recommended value for the VLAN Priority for the PC port is 3.
