3. Using the LCD Configuration Menu
This chapter provides detailed information to configure the IP8820, IP8830 and IP8840 phones
using the LCD Configuration Menu. The LCD displays the configuration menu and softkey
functions. The softkeys and dial pad select menu items and input values. A configuration
session begins by pressing the Settings (
) button, which accesses the LCD Configuration
Menu shown in Figure 3-1
. Select the desired menu item using one of the following methods:
 Use the dial pad to input the menu item number. This is the digit displayed in front of the
item or
 Navigate with the [Next]-[Previous] softkeys to highlight the item and select with the [OK]
softkey.
Configuration Menu
1.Network Configuration
2.SIP Configuration
3.Phone Settings
4.Call Preferences
5.Directory
6.Set to Default
7.Lock/Unlock Config
8.Information
9.Reboot
Figure 3-1 LCD Configuration Main Menu
When the desired parameter is reached, enter data with the dial pad or select values with the
softkeys. Refer to Figure 3-2
for the complete menu.
Sections 3.1
to 3.3 give general information on use of the LCD Menu. The remaining
paragraphs of this section give descriptive and procedural information for each parameter of the
menu. Information is organized to follow the structure of the menu as shown in Figure 3-2
. The
menu shown in Figure 3-2
applies to IP Phones using the wired network connection. When
employing the WiFi module, the Network Configuration sub-menu is changed as described in
section 5
of this guide.
