IP8820/IP8830/IP8840
Installer Guide
15
3.1 Navigating the LCD Configuration Menu
The IP phone must be idle to access the configuration menu and may be password protected
(Locked). If locked, advanced configuration parameters can be viewed however, data entry is
not possible. Refer to section
3.3.
To access the configuration menu:
Press the Settings (
) button.
To select an item:
Dial the digit associated with the menu item or
Use the [Next]-[Previous] softkeys to move the cursor to the item, then press the [OK]
softkey.
The bottom line of the display shows three (3) softkey functions at a time. Additional softkey
functions are available when the right arrow, , appears in the bottom-right corner of the LCD.
Use the right navigation button,
, to view the additional softkeys.
To return to a previous branch in the menu when the return arrow,
, appears in the bottom left
corner of the LCD:
Press the left navigation button,
.
To exit the configuration menu:
Press the Settings (
)
button.
3.2 Entering Values with the Dial Pad and Softkeys
Use the dial pad to input numbers, letters, special characters, and a period. The [Mode] softkey
displays to indicate a parameter can accept an alphanumeric entry. Selecting the [Mode]
softkey switches the dial pad mode. The dial pad mode displays in the upper-right corner as
for numeric,
for upper case characters and for lower case characters. Appendix E.
defines the relationship between the dial pad digits and characters.
To enter characters with the dial pad, use the digit with the desired character. Press the same
digit repeatedly until the desired character appears in the LCD. After entering a character,
pause to allow the cursor to move to next character position.
Other special entries include:
- To enter a period or dot (for example, to input an IP address), press asterisk, , on the
dial pad.
- To delete a letter in front of the cursor, press the backspace, [], softkey
- To clear an entire string, press the [Clear] softkey.
