IP8820/IP8830/IP8840
Installer Guide
76
- Pause defines the position in the number where, if matched, the phone will pause for
additional digits before processing the call. The pause duration is programmable
under the [Dial] section of the configuration file and has a default of 3 seconds.
- Extra
– IP address of phone to send a call if a match occurs. The call is placed to
the IP address in place of the modified number.
In addition to the dial pad digits, special characters can be defined.
- A ‘?’ matches any single digit.
- A “~” matches a string of characters of any length.
- A “,” locates the position of a Pause.
- A “.” returns dial tone”
The following are examples of dial plans using the Routing Table.
Simple Dial Plan
Customer requirements:
Process the call after any 7 digit number is dialed or if the Operator is dialed at digit ‘0’.
Number TRNC Pre Post Pause Extra
0?????? 0 NULL NULL ?, 0.0.0.0
??????? 0 NULL NULL NULL 0.0.0.0
From the above table, if the user dials 0 as the first digit, the IP Phone will pause for additional
digits. After the pause, if no additional digits are dialed, the phone places a call to the Operator.
In addition, after the user dials any seven digits, the call is processed.
Complex Dial Plan
Customer requirements:
Process the call after the local operator at 0, long distance operator at 00, a four-digit local
extension number starting with 3,4 or 5, a seven-digit local number prefixed by an 8, two-digit
number preceded by star (‘*’), a ten digit long distance number prefixed by 91, or an
international number starting with 9011 is dialed.
Number TRNC Pre Post Pause Extra
0? 0 NULL NULL ?, 0.0.0.0
00 0 NULL NULL NULL 0.0.0.0
3??? 0 NULL NULL NULL 0.0.0.0
4??? 0 NULL NULL NULL 0.0.0.0
5??? 0 NULL NULL NULL 0.0.0.0
8??????? 0 NULL NULL NULL 0.0.0.0
*?? 0 NULL NULL NULL 0.0.0.0
91?????????? 0 NULL NULL NULL 0.0.0.0
0 9011~ 0 NULL NULL NULL 0.0.0.0
