3-66
Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
WLAN settings (Access point)
Setting Description
Wireless LAN Off, Station and Access point
Restart Wireless LAN Restart the wireless LAN function.
If you switch between the station and the access point, please perform a restart.
AUTO SETTINGS
(WPS)
WPS system Push button method, PIN method
PIN
method
PIN code Enter the PIN code displayed on the station you want to connect to.
WPS execution Execute WPS.
SSID input Character string: up to 32 characters
Encryption method NONE, WEP, WPA-PSK/WPA2-PSK
WEP WEP key 10 digits for WEP64 and 26 digits for WEP128 alphanumeric characters.
WPA-PSK/WPA2-
PSK
Password Set a password with 8 to 63 alphanumeric characters.
Stealth Off, On
Channel 1ch to 13ch
11n Off, On
Apply settings (Restart wireless LAN ) The encryption method, WEP key and password settings are reflected.
IP address automatic
acquisition
IP address 192.168.xxx.1: the part other than xxx is fixed. xxx: 0 to 255
Apply settings The contents of the TCP-IP settings are reflected.
Wired LAN detailed settings
Setting Description
IP address automatic acquisition Do not use, Use
IP address 0 to 255.0 to 255.0 to 255.0 to 255
(only when the IP address automatic acquisition is not used.)
Subnet mask 0 to 255.0 to 255.0 to 255.0 to 255
(Only when the IP address automatic acquisition is not used.)
Gateway 0 to 255.0 to 255.0 to 255.0 to 255
(Only when the IP address automatic acquisition is not used.)
DNS address 0 to 255.0 to 255.0 to 255.0 to 255
(Only when the IP address automatic acquisition is not used.)
Apply settings The contents of the TCP-IP settings are reflected.
Network settings
Setting Description
New Line Code CR+LF
・
LF
・
CR
I/F command function I/F command function Off, On
Port number 1024
～
65535
Keep Alive Off, 10 seconds, 30 seconds, 1 minute, 10 minutes, 30 minutes, 1 hour
FTP Client Settings Destination FTP server Enter up to 127-character string
User Name Enter up to 31-character string
Password Enter up to 31-character string
Port Number 0 to 65535
PASV Mode Off, On
Encryption method Off, Explicit, Implicit
FTP server connection test Execute a connection test
File captured when the backup is
successful
Leave, Delete
FTP Server Settings FTP Server Function Off, On
Anonymous connection Disable, Enable
User name Enter up to 31-character string
Password Enter up to 31-character string
Port number 0 to 65535
To Next Page
